Country Of OriginUSA
Dishwasher SafeYes
Matte Finish Vs Satin FinishMatte Finish
Cast Iron Vs PorecelainPorcelain Coated Grates
Extended Service Plan ParentEW08IW1Y, EW08IW2Y, EW08IW4Y
Product To Product PairsWVU37UC0FS, WVW57UC0FS, WVU57UC0FS, WVW53UC0HV, WVW53UC0LS, WVW51UC0LS, WVU17UC0JW, WVW73UC0LS, UXT5530AAS, WVU17UC0JS, UVL5430JSS
Optional AccessoriesW10675028, W10655450, W10731887, W10675026, W10731885, W10675027, W10731886, W10655449, W10115773, W10655448, W11692811, W11123246
Volts120
Hz60
Amps15
Power Cord IncludedYes
ULYes
CULYes
ADA CompliantYes
Handle MaterialMetal
Door RemovableYes
Drawer TypeStorage Drawer
Handle TypeReach-Through Handle
Knob TypeWeighted
Knob ColorBlack
Electronic Display TypeLCD
Cooktop Element StyleSealed Burners
Cooktop Control LocationFront
Cooktop Control TypeKnobs
Cooktop Surface ColorBlack
Left Rear Element Burner TypeSimmer
Number Of Cooking Element Burners5
Right Rear Element Burner TypeSealed Burner
Center Rear Element Burner TypeSealed Burner
Left Front Element Burner TypeHigh Output
Left Rear Element Burner Power5000BTU
Right Rear Element Burner Power9500BTU
Auto Re IgnitionNo
Number Of Grates2
Ignition TypeDirect Spark Ignition
Left Front Element Burner Power17000BTU
Center Rear Element Burner Power10000BTU
Right Front Element Burner Power13000BTU
Right Front Element Burner TypeDual Flame
Grate DetailsDishwasher Safe; Hinged; Matte Finish; Porcelain Coated Cast Grates
GriddleYes
Hot Surface Indicator LightNo
Automatic Convection Conversion Temperature AdjustYes
Power Outage CompatibleYes
Heating Element On Indicator LightNo
Works WithAmazon Alexa; Android; Google Assistant; iOS
ConnectivityApp; Remote Access; Voice Controlled; WiFi
Oven ConfigurationSingle Oven
Range ConfigurationSlide-In
Broiler LocationTop of Oven
Cooktop Surface MaterialPorcelain Coated Steel
Hidden Bake ElementYes
Oven Control LocationFront Control
Interior ColorGrey
Oven Cooking SystemConvection
Number Of Oven Lights1
Oven Light TypeIncandescent
Broiler Element Power11000BTU
Oven Control TypeElectronic Touch
Number Of Oven Racks3
Oven Light Switch LocationTop of Console
Bake Element Power18000BTU
Convection Element Power Watts900
Number Of Rack Guides7
Convection Element TypeTrue
Convection FunctionsBake Broil Roast Both
Oven Interior Depth In Inches20.75
Oven Interior Width In Inches24.38
Oven Rack Type2 Standard and 1 Max Capacity
Oven Cleaning TypeAquaLift® Self-Clean
Size In30
Range TypeSlide-in
Fuel TypeGas
Whr RangeADA Compliant; Bladed Knob; EZ-2-Lift™ Hinged Grates; Frozen Bake™ Technology; Scan-to-Cook Technology; Self-Cleaning; Touchscreen; Whirlpool Handle
Carton Depth30.5"
Carton Height43.5"
Carton Width31.5"
Depth Closed Excluding Handles27.0"
Depth Closed Including Handles28.63"
Depth With Door Open 90 Degree48.88"
Depth28.63"
Gross Weight223.0 lbs.
Height36.0"
Width29.88"
Cutout Depth24.0"
Cutout Height36.0"
Cutout Width30.0"
Capacity FT3 (cubic feet)5.8
